Gabion Mesh Cages Wall For Preventing Riverbed From Washing Out
Gabion Cage Description :
Gabion wall cages are made of heavy galvanized wire / ZnAl (Golfan) coated wire / PVC coated wires, the mesh shape is
hexagonal style. The gabion boxes are used widely in slope
protection, foundation pit suporting, mountain rock holding, river
and dams scour protection.
Gabion boxes can be supplied in various lengths, widths and
heights. In order to strengthen the boxes,all the edges of the
structure shall be selvedged with wire of bigger diameter.
Hole size: 60*80mm,80*100mm,80*120mm,100*120mm,120*150mm etc
Wire size: 1.Mesh wire: 2mm-4mm
2.Edge wire: 0.5mm-1mm
3.Binding wire: 2.2mm
Tensile resistance: Above 38kg/m2 380N/mm
Gabion Cage Material :
1. hot-dip galvanized low carbon steel wire,
2. Zinc-5%Al or10%Al-mixed rare earth alloy coating, also named
Galfan. lifetime 3times min than hot-dip galvanized gabion.
3. PVC coated , PVC coated on hot-dip galvanized steel wire and
Galfan, many kinds of color
4. Tensile strength: 350-500Mpa,Elongation ≥12%,according to
EN10223-3
5. zinc coating: mesh wire≥230g/M2,selvedge wire≥245g/M2,lacing
wire ≥230g/M2
| gabion specifications | Mesh hole modle |
| 8x10cm | 6x8cm |
| Length(m) | Width(m) | Height(m) | Galvanized or PVC coated | Galvanized or PVC coated |
| Mesh diameter | Zinc | Mesh diameter | Zinc |
| 2 | 1 | 1 | 2.7mm | >245g/m² | 2.0mm | >215g/m² |
| 3 | 1 | 1 | Side wire diameter | Zinc | Side wire diameter | Zinc |
| 4 | 1 | 1 | 3.4mm | >265g/² | 2.7mm | >245g/m² |
| 6 | 1 | 1 | Binding wire diameter of 2.7m | Binding wire diameter of 2.0m |
Gabion Cage Applications :
The gabion box can be used for slope support, foundation pit
support, mountain rock surface hanging network spraying,slope
planting (greening), railway expressway isolation and protection
fence, it can also be made into box cages, net pads for river, dam
and seawall protection against scour, reservoir, river closure
boxes.The most serious disaster of a river is the damage caused by
the erosion of its Banks by the flow of water.Therefore, in dealing
with the above problems, the application of the grid structure is
one of the best solutions, which can permanently protect the
riverbank.
1. The flexible structure can adapt to the change of slope without
being damaged, and has better safety and stability than the rigid
structure.
2. Strong anti-scour ability, capable of bearing the maximum flow
speed up to 6m/s.
3. The structure is water permeable in nature and highly tolerant
to the natural and filtration effects of groundwater. The suspended
solids and silt in the water can be deposited in the stone filling
joints, which is conducive to the growth of natural plants and the
gradual restoration of the original ecological environment.
Gabion Cage Advantage :
1.The construction is simple,only needs to put the stone into the
cage seal can, no special technology is required, and no water and
electricity is required.
2.The cost is low, and the cost per square meter is only about 3
USD.
3.The landscape and protective effects are good.The combination of
engineering measures and plant measures adopted by the gabion box
technology can effectively prevent soil and water loss, and the
landscape effect is quick, and the landscape effect is more natural
and rich.
4.The service life is long, and the technology life of the gabion
box is several decades, and the maintenance is generally not
needed.Because of this, the dam protection project of huangshi
section of the Yangtze river, the flood prevention project of taihu
lake, the three gorges sanduping bank protection project and so on
have adopted this technology.
