Low Carbon Steel Wire Welded 75*75mm Military Defensive Barriers
Use For Shooting Field
Product Description:
Welded 75*75mm Military Defensive Barriers is a multi-cellular barrier system lined with heavy-duty,
non-woven polypropylene geotextile and manufactured from welded
Zinc-Aluminium coated steel mesh.
Known as a Military Gabion Barrier Bastion Sand Wall , it consists
of collapsible wire mesh frames, lined with heavy duty canvas or
other material. The boxes are then filled with dirt or sand ,
preferably with a front-end loader , to make a barrier resistant to
small arms fire and shrapnel.
Material: Low carbon steel wire, galbanized wire, Zinc-Aluminum coated wire
Wire Diameter: 4.0mm 5.0mm
Spring Diameter: 4.0mm 5.0mm
Mesh Opening: 50*50mm, 75*75mm, 76.2*76.2mm, 50*100mm, 100*100mm, ect
Geotextile: 250gsm 300gsm Heavy duty non-woven polypropylene
Geotextile color: White, Sand color, Military Green
Details of Welded Military Defensive Barriers:
| Unit Type | Height (M) | Width (M) | Length (M) | Internal Cells |
| SX-01 | 1.37 | 1.08 | 10 | 9 |
| SX-02 | 0.61 | 0.61 | 1.22 | 2 |
| SX-03 | 1.0 | 1.0 | 10 | 10 |
| SX-04 | 1.0 | 1.5 | 6 | 6 |
| SX-05 | 0.61 | 0.61 | 3.05 | 5 |
| SX-06 | 1.68 | 0.61 | 3.05 | 5 |
| SX-07 | 2.21 | 2.13 | 8.25 | 4 |
| SX-08 | 1.37 | 1.22 | 10 | 9 |
| SX-09 | 1.0 | 0.76 | 6.84 | 9 |
| SX-10 | 2.13 | 1.52 | 7.6 | 5 |
Application of Military Defensive Barriers:
Peripheral security and defense wall
Shelter for personnel and materials
Defensive firing position sentry
Explosive and contraband search area
Highway/Border crossing inspection station
Flood control retaining wall beach erosion
Coastal Area Protection Project
Advantages of Military Defensive Barriers:
1. Removable
It is assembled by panels and spring wires, and can be folded into
a whole during loading and transportation.
2. Anticorrosion
The raw material is hot-dip galvanized wire, which can be used for
10 years or more and is suitable for external protection.
3. Easy installation
When you get it, open it in a spacious place and fill it with sand
and mud. Even 2-3 people can finish it.
4. Rapid displacement
When you want to use it in another place, just move it and it can
be used many times.
5. Easy to repair
If a part is damaged, throw it away and connect it with a new one.
FAQ:
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is
15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay
the cost of freight.
Q: What is your terms of payment ?
A: Payment<=5000 USD, 100% in advance. Payment>=5000 USD, 30%
T/T in advance ,balance before shipment.
If you have another question, please feel free to contact us .
