    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments

    Ask Lasest Price
    Brand Name : SHUXIN
    Model Number : Military Sand Wall
    Certification : CE SGS ISO COC
    Price : Negotiated
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 500 units per week
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments

    China factory sell Galvanized Defensive Barrier Welded Gabion Baskets

    Description:


    1.Units can be both lined or unlined in other word it can be used together to any length, and can be stacked for

    additional height.

    2. The spiral hinged corners allows flat packing for ease of transportation

    3. The welded mesh frame is of highly durable construction

    4. The Galfan coated welded mesh frame is ideal for containing large amounts of the geavy fill material that

    gives the system its strength.

    5. The non-woven geotextile liner allowing a wide range of fill material

    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment RevetmentsISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments

    Product application:

    ∗Perimeter Security and Defence Walls,

    ∗Equipment Revetments,

    ∗ garden landscaping decorative

    ∗Personnel and Material Bunkers, Observation Points, Defensive Firing Positions

    ∗Guard Posts, Explosives and Contraband Search Areas, Highway Checkpoints,

    ∗Border Crossing Checkpoints, Protecting Existing Structures, Flood control retaining wall

    ∗Coastal Erosion, Protection engineering of seaside area.

    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment RevetmentsISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments

    Quick View of Military Sand Wall :


    Material : Low-carbon steel wire
    Wire Diameter : 4-5.0mm
    Spring Diameter : 4.0-4.5mm
    Mesh Hole : 76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm
    Panel Size : 2.21× 2.13m, 1.37× 1.06m, 0.61× 0.61m, 1.37× 1.22m
    Geotextile : In heavy duty non-woven polypropylene.
    Finish : Hot Dipped Galvanized after /before welding, Galfan Coated before welding

    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments

    The Common Specification of Military Sand Wall as followed:

    MODELHeightWidthLengthNO. of Cells
    SX-14'6"(1.37M)3'6"(1.06M)32'(10M)9 cells(1*4, 1*5)
    SX-27'(2.1M)3'6"(1.06M)108'(33M)30 cells(6*5)
    SX-32'(0.61M)2'(0.61M)4'(1.21M)2 cells
    SX-43'3"(1.0M)3'3"(1.0M)32'(10M)10 cells(2*5)
    SX-52'(0.61M)2'(0.61M)10'(3.05M)5 cells
    SX-65'6"(1.68M)2'(0.61M)10'(3.05M)5 cells
    SX-77'3"(2.21M)7'(2.13M)90'(27.74M)13 cells(2*4,1*5)
    SX-84'6"(1.37M)4'(1.22M)32'(10M)9 cells(1*4, 1*5)
    SX-93'3"(1.0M)2'6"(0.76M)30'(9.14M)12 cells(2*6)
    SX-107'(2.12M)5'(1.52M)95'(30.5M)20 cells(4*5)
    SX-113'3"(1.0M3'3"(1.0M)3'3"(1.0M)1 Cell
    SX-127'3"(2.21M)7'3"(2.21M)7'3"(2.21M)1 Cell

    Packing and Shipping

    ∗Wrapped with shrink film then on pallet
    ∗Bulk load
    ∗Customized packing is available.


    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments

    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments

    ISO COC Galvanized Defensive Barrier Welded Gabion Baskets For Equipment Revetments
