    Hexagon Pvc Coated Stainless Steel Gabion Baskets For Preventing

    Ask Lasest Price
    Brand Name : SHUXIN
    Certification : ce
    Price : Negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Delivery Time : 5-15 DAYS
    • Product Details
    • Company Profile

    Hexagon Pvc Coated Stainless Steel Gabion Baskets For Preventing

    Hingh Quality Hexagon PVC Coated Gabion Wire Mesh Basket For Preventing


    Gabion basket also named gabion box, is weaved by corrosion resistance, high strength and good ductility galvanized wire or PVC coating wire through mechanical. Wire's material is zinc-5% aluminum alloy (galfan), low carbon steel, stainless steel or iron.


    Gabion mattress is similar to gabion basket. But gabion mattress's height is lower than gabion basket, structure is flat and big. Gabion basket and gabion mattress are stone containers, uniformly partitioned into internal cells, interconnected with other containers and filled with stone at site to form flexible, permeable, monolithic structures to control and guide water or flood, protect dam or seawall, or used as retaining walls, channel lining and other applications.


    Gabion Specification :

    Gabion material: galvanized wire, Zn-Al(Galfan) coated wire/PVC coated wire

    Gabion wire diameter: 2.2mm,2.7mm,3.05mm etc.

    Gabion size : 1x1x1m,2x1x0.5m,2x1x1m,3x1x1m,3x1x0.5m,4x1x1m,4x1x0.5m,4x2x0.3m,

    5x1x0.3m,6x2x0.3m etc.,customized is available.

    Gabion mesh size:60*80mm,80*100mm,100*120mm,120*150mm,or customized

    Gabion application: can be widely used in flood controlling,retaining wall,river bank protection,slope protection


    Gabion box

    (mesh size):

    80*100mm

    100*120mm

    Mesh Wire diameter2.7mmzinc coating:60g,245g, ≥270g/m2
    Edge wire diameter3.4mmzinc coating:60g,245g, ≥270g/m2
    Tie wire diameter.2.2mmzinc coating:60g,≥220g/m2

    Gabion mattress

    (mesh size):

    60*80mm

    Mesh wire diameter.2.2mmzinc coating:60g, ≥220g/m2
    Edge wire diameter.2.7mmzinc coating:60g,245g, ≥270g/m2
    Tie wire diameter.2.2mmzinc coating:60g, ≥220g/m2

    special sizes Gabion

    are available


    Mesh wire diameter2.0~4.0mm

    superior quality,competitive price and

    considerate service

    Edge wire diameter2.7~4.0mm
    Tie wire diameter2.0~2.2mm

    Gabion wire mesh basket advantage

    Economic. Just fill the stone into the gabion and seal it.

    Easy to install.

    High zinc coating thus anti-rust and anti-corrosive.

    Low cost and High security.

    Good permeation can prevent the damage by hydrostatic pressure
    Less transport freight. It can be folded together for transport and further installation.


    Gabion basket application:

    Control and guide of water or flood

    Flood bank or guiding bank

    Preventing of rock breaking

    Water and soil protection

    Bridge protection

    Strengthening structure of soil

    Protection engineering of seaside area


    Gabion box Features

    Strong structure, flat surface, good corrosion resistance, oxidation resistance, etc.


    Construction steps


    The construction combination and stone filling steps can be summarized as follows: Each unit structure is combined before placement The structure of the pad combination is placed at the construction site, and the cell structures are connected by tie wire. Rock fill in structure Cover the structure and fasten it with tie wire.
