Square Hole 76.2 X 76.2mm Defense Hesco Blast Walls

Military sand wall hesco barrier Military Hesco Barrier Fill Sand Hesco Blast wall

Material: Low-carbon steel wire
Wire Diameter : 4-5.0mm
Spring Diameter : 4.0-4.5mm
Mesh Hole : 76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm
Panel Size: 2.21× 2.13m, 1.37× 1.06m, 0.61× 0.61m, 1.37× 1.22m
Geotextile : In heavy duty non-woven polypropylene.
Finish : Hot Dipped Galvanized after /before welding, Galfan Coated before welding

Hesco Barrier Specification

Model	Height	Width	Length	Internal Cells
SX-1(Mil 1)	54”(1.37m)	42”(1.06m)	32’9”(10m)	5+4=9 cells
SX-2(Mil 2)	24”(0.61m)	24”(0.61m)	4’(1.22m)	2 cells
SX-3(Mil 3)	39”(1.0m)	39”(1.0m)	32’9”(10m)	5+5=10 cells
SX-4(Mil 4)	39”(1.0m)	60”(1.52m)	32’9”(10m)	5+5=10 cells
SX-5(Mil 5)	24”(0.61m)	24”(0.61m)	10’(3.05m)	5 cells
SX-6(Mil 6)	66”(1.68m)	24”(0.61m)	10’(3.05m)	5 cells
SX-7(Mil 7)	87”(2.21m)	84”(2.13m)	91’(27.74m)	5+4+4=13 cells
SX-8(Mil 8)	54”(1.37m)	48”(1.22m)	32’9”(10m)	5+4=9 cells
SX-9(Mil 9)	39”(1.0m)	30”(0.76m)	30’(9.14m)	6+6=12 cells
SX-10(Mil 10)	87”(2.21m)	60”(1.52m)	100’(30.5m)	5+5+5+5+5=20 cells
SX-11(Mil 11)	48”(1.22m)	12”(0.30m)	4’(1.22m)	2 cells
SX-12(Mil 12)	84”(2.13m)	42”(1.06m)	108’(33m)	5+5+5+5+5+5=30 cells
SX-19(Mil 19)	108”(2.74m)	42”(1.06m)	10’5”(3.18m)	6 cells
