Anti-Corrosive 2x1x1m Gabion Baskets Box Design With Stone Filled
Cage
Gabion mesh/ gabion box material:
(1) Galvanized steel wire: diameter 2.0MM-4.0MM, tensile strength
>380Mpa, zinc :240g / m2.
(2) Zinc 5% Aluminum - wire diameter 1.0MM-3.0MM, tensile strength
>380Mpa.
(3) coated galvanized steel wire: low carbon steel wire PVC coated.
(4) Woven Mesh Opening: Hexagonal Wire Pattern 60*80mm,
80*100mm,100*120mm,
(5) Size: 1*1*1m,2*1*1m, 4*1*1x2m, other size can be produced as
requested
Gabion wire mesh box advantage
(1) It is convenient to use, and can be used only by tiling the net
surface into wall surfaces and building cement;
(2) The construction is simple and does not need special
technology;
(3) Strong ability to resist natural damage, corrosion and adverse
weather effects;
(4) Can withstand large-scale deformation without collapsing. It
plays a role in fixing heat preservation and heat insulation.
(5) The excellent technological foundation ensures the uniformity
of coating thickness and has stronger corrosion resistance;
(6) Save transportation costs. It can be shrunk into small rolls
and wrapped in moisture-proof paper, occupying little space.
(7) Heavy hex net is made of high-quality low-carbon steel wire
with galvanized large wire number. The tensile strength of the
steel wire is not less than 38kg/m2, and the diameter of the steel
wire can reach 2.0 mm-3.2 mm. The surface of the steel wire is
usually protected by hot galvanizing. The thickness of the
galvanized protective layer can be made according to the
requirements of
customers, and the maximum amount of galvanizing can reach 300g/m2.
Gabion box Features
(1) Economy. Just put the stone into the cage and seal it.
(2) The construction is simple and does not need special
technology.
(3) Strong ability to resist natural damage, corrosion and adverse
weather effects.
(4) can withstand large-scale deformation without collapsing.
(5) Silt between the cage stones is beneficial to plant production
and can be fused with the surrounding natural environment.
(6) It has good permeability and can prevent damage caused by
hydrostatic force. It is conducive to the stability of mountain
slopes and beaches.
(7) Save transportation costs. It can be folded up for
transportation and assembled on the construction site.
(8) Good flexibility: no structural joints, and the overall
structure has ductility.
(9) Corrosion resistance: Galvanized materials are not afraid of
seawater.
| Gabion basket |
| Mesh wire | 2.0mm-4.0mm |
| Mesh size | 60*80mm, 80*100mm, 90*110mm, 100*120mm, 120*150mm |
| Selvedge wire | thicker 0.5mm-1.0mm than mesh wire |
| Tie wire | 2.2mm, 2.5mm |
| Gabion size | 1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m, 6*2*0.3m |
| Surface treatment | high zinc coated, HD galvanized, PVC coated |
Gabion basket application:
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside area
Construction steps
The construction combination and stone filling steps can be
summarized as follows: Each unit structure is combined before
placement The structure of the pad combination is placed at the
construction site, and the cell structures are connected by tie
wire. Rock fill in structure Cover the structure and fasten it with
tie wire.
