Product Overview
Razor Barbed Wire, also known as blade netting, bladegill net, is a new type of protective net. Blade barbed wire has beautiful, economic and practical, good anti-resistance effect, convenient construction and other excellent characteristics, at present, blade barbed wirehas been widely used in many countries of industrialand mining enterprises, garden apartments, border posts,military fields, prisons, detention centers, govemment buildings and other countries of the security facilitios.
Products Production
Process: Razor blade gill net is a kind of baffle equipment made of hot galvanized steel orstainless steel sheet with sharp blade, high tension galvanized steel wire or stainless steel wire as core wire. Because of the unique shape of the gillnet is not easy to touch,it can achieve excellent protective isolation effect.
Materials: The main materials of the products are a alvanized sheet and stainless steel sheet.
More Types
Categories:Razor Barbed Wire is roughly divided into spiral, straight line, spiral cross type three forms.Blade thorn rope according to different installation methods can be divided into:
① (snake belly) spiral blade thorn rope,
② linear blade thorn rope,
③ flat blade thorn rope,
④ blade thorn rope welding net and so on.
Razor Barbed Wire is also named concertina razor wire, razor fencing wire, razor blade wire . It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
| Wire diameter | 2mm 2.5mm 2.8mm ( customized ) |
| Thickness | 0.5 mm - 0.6 mm. |
| Razor length | 12 mm - 21 mm. |
| Razor width | 13 mm - 21 mm. |
| Barb spacing | 26 mm - 100 mm. |
| Outside diameter | 450 mm - 960 mm. |
| Number of loops | 33 mm - 102 mm. |
| Standard length per coil | 8 m - 16 m. |
| Razor barbed types | Single coil and cross type. |
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
| 450mm | 33 | 7-8m | CBT-60/65 | Single coil |
| 500mm | 56 | 12-13m | CBT-60/65 | Single coil |
| 700mm | 56 | 13-14m | CBT-60/65 | Single coil |
| 960mm | 56 | 14-15m | CBT-60/65 | Single coil |
| 450mm | 56 | 8-9m | BTO-12/22/25/30 | Cross type |
| 500mm | 56 | 9-10m | BTO-12/22/25/30 | Cross type |
| 600mm | 56 | 10-11m | BTO-12/22/25/30 | Cross type |
| 600mm | 56 | 8-10m | BTO-12/22/25/30 | Cross type |
| 700mm | 56 | 10-12m | BTO-12/22/25/30 | Cross type |
| 800mm | 56 | 11-13m | BTO-12/22/25/30 | Cross type |
| 900mm | 56 | 12-14m | BTO-12/22/25/30 | Cross type |
| 960mm | 56 | 13-15m | BTO-12/22/25/30 | Cross type |
| 980mm | 56 | 14-16m | BTO-12/22/25/30 | Cross type |
