Geotextile Welded Galvanized Gabion Galfan Defensive Sand Filled
Barriers For Sale In Jordan
Sand Filled Barriers is a multi-cellular barrier system lined with heavy-duty,
non-woven polypropylene geotextile and manufactured from welded
Zinc-Aluminium coated steel mesh. Known as Defensive Sand Filled
Barriers , it consists of collapsible wire mesh frames, lined with
heavy duty canvas or other material. The boxes are then filled with
dirt or sand , preferably with a front-end loader , to make a
barrier resistant to small arms fire and shrapnel.
Usually, the materials for welding gabion boxes are hot-dip
galvanized wire and Galfan coated wire, which are corrosion
resistant, high in strength and long in service life. Wire
diameter: 5.0mm (thick enough to withstand impact)
- Spring wire for connecting mesh plates
Usually, the spring wire is made of the same wire as the metal
panel. It informs the net cage to load sand or stones together with
the panel. Spring wire diameter: 4.0 mm
We have a full-automatic machine, which is mainly used for
thick-line welding of screen plates, and deep welding points make
the screen plates firmer. Mesh: 75mm * 75mm (standard and strong)
You can also make bigger holes according to customer's
requirements.
It has various colors: sand, brown, gray and military green.
Generally, the weight of geotextile is 300 GSM and our geotextile
is uniform in thickness, reaching the national standard.
Sand Filled Barriers Specification
| Model | Height | Width | Length | Internal Cells |
| SX-1(Mil 1) | 54”(1.37m) | 42”(1.06m) | 32’9”(10m) | 5+4=9 cells |
| SX-2(Mil 2) | 24”(0.61m) | 24”(0.61m) | 4’(1.22m) | 2 cells |
| SX-3(Mil 3) | 39”(1.0m) | 39”(1.0m) | 32’9”(10m) | 5+5=10 cells |
| SX-4(Mil 4) | 39”(1.0m) | 60”(1.52m) | 32’9”(10m) | 5+5=10 cells |
| SX-5(Mil 5) | 24”(0.61m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-6(Mil 6) | 66”(1.68m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-7(Mil 7) | 87”(2.21m) | 84”(2.13m) | 91’(27.74m) | 5+4+4=13 cells |
| SX-8(Mil 8) | 54”(1.37m) | 48”(1.22m) | 32’9”(10m) | 5+4=9 cells |
| SX-9(Mil 9) | 39”(1.0m) | 30”(0.76m) | 30’(9.14m) | 6+6=12 cells |
| SX-10(Mil 10) | 87”(2.21m) | 60”(1.52m) | 100’(30.5m) | 5+5+5+5+5=20 cells |
| SX-11(Mil 11) | 48”(1.22m) | 12”(0.30m) | 4’(1.22m) | 2 cells |
| SX-12(Mil 12) | 84”(2.13m) | 42”(1.06m) | 108’(33m) | 5+5+5+5+5+5=30 cells |
| SX-19(Mil 19) | 108”(2.74m) | 42”(1.06m) | 10’5”(3.18m) | 6 cells |
Sand Filled Barriers Advantages
Secure & reliable
Once filled with soil, sand or gravel, forms a solid and strong
barrier with exceptional strength and structural integrity to
protect personnel and equipment from enemy fire. For example:
Two feet thick barriers can be used to stop rifle bullets and shell
fragments.
Four feet thick barriers can prevent most car bombs.
Five feet thick barriers is ideal for preventing penetration and
explosion fragments from rocket propelled grenade.
Convenient usage
HESCO bastion barrier can be used in separate cell or some cells
joined together by joint pins to suit different needs of your
projects. Almost any locally filling material can be used such as
soil, sand, gravel, crushed rock and various other granular
materials.
Labor saving design
Can be collapsed and stacked on pallets for easy package, handling
and transport, so that it efficiently saves labor cost.
Quick & easy assembly
Provides the easiest deploy methods - just unfold it and fill it
using minimal manpower or commonly available equipment. Previously,
sandbag barrier is considered a slow undertaking as a person can
only fill about 20 sandbags per hour. Yet our KNSCO do ten times
the work.
Sand Filled Barriers Application
1. Military fortifications Most armies use defense barriers to
build military fortifications because they can be stacked on top of
each other. You can change the width and height according to your
requirements. More simple and flexible.
2. Shooting range Nowadays, many people use defense barriers to
build shooting ranges because of its high defense strength and
safety.
3. Flood control Defense barriers are becoming more and more
popular and easy to assemble, and good permeability. Most countries
near coastlines choose defense barriers as flood prevention walls.
Even around the hotel, they erected protective walls.
Sand Filled Barriers Features
1. having a Galfan coated steel mesh framework
2. integrated cells to provide internal structural integrity.
3. exceptional strength and structural integrity
4. High tensile and anti-impact capability
5. making transportation efficient and rapid
