    Hexagon 2.0mm Pvc Coated Gabion Baskets Wall Cages For Preventing

    Ask Lasest Price
    Brand Name : SHUXIN
    Certification : CE ISO
    Price : Negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Delivery Time : 5-15 DAYS
    • Product Details
    • Company Profile

    Hexagon 2.0mm Pvc Coated Gabion Baskets Wall Cages For Preventing

    Hexagon Pvc Coated Gabion Basket Wall Cages For Preventing


    Gabion basket is an ecological grid structure. The stone cage net is mechanically woven from low-carbon steel wire with high corrosion resistance, high strength and ductility or PVC-coated steel wire. The box-shaped structure made by the net is the stone cage.

    The diameter of the low carbon steel wire used varies according to engineering design requirements. Generally between 2.0-4.0mm, the tensile strength of the steel wire is not less than 38kg/m2, and the metal coating weight is generally higher than 245g/m2.

    The diameter of the edge wire of the gabion mesh is generally larger than the diameter of the wire. The length of the twisted part of the double wire shall not be less than 50mm. To ensure that the metal coating and PVC coating of the twisted part of the steel wire are not damaged.


    Gabion Specification :

    Gabion material: galvanized wire, Zn-Al(Galfan) coated wire/PVC coated wire

    Gabion wire diameter: 2.2mm,2.7mm,3.05mm etc.

    Gabion size : 1x1x1m,2x1x0.5m,2x1x1m,3x1x1m,3x1x0.5m,4x1x1m,4x1x0.5m,4x2x0.3m,

    5x1x0.3m,6x2x0.3m etc.,customized is available.

    Gabion mesh size:60*80mm,80*100mm,100*120mm,120*150mm,or customized

    Gabion application: can be widely used in flood controlling,retaining wall,river bank protection,slope protection


    Gabion box

    (mesh size):

    80*100mm

    100*120mm

    Mesh Wire diameter2.7mmzinc coating:60g,245g, ≥270g/m2
    Edge wire diameter3.4mmzinc coating:60g,245g, ≥270g/m2
    Tie wire diameter.2.2mmzinc coating:60g,≥220g/m2

    Gabion mattress

    (mesh size):

    60*80mm

    Mesh wire diameter.2.2mmzinc coating:60g, ≥220g/m2
    Edge wire diameter.2.7mmzinc coating:60g,245g, ≥270g/m2
    Tie wire diameter.2.2mmzinc coating:60g, ≥220g/m2

    special sizes Gabion

    are available


    Mesh wire diameter2.0~4.0mm

    superior quality,competitive price and

    considerate service

    Edge wire diameter2.7~4.0mm
    Tie wire diameter2.0~2.2mm

    Gabion wire mesh basket advantage

    Economic. Just fill the stone into the gabion and seal it.

    Easy to install.

    High zinc coating thus anti-rust and anti-corrosive.

    Low cost and High security.

    Good permeation can prevent the damage by hydrostatic pressure
    Less transport freight. It can be folded together for transport and further installation.


    Gabion basket application:

    Control and guide of water or flood

    Flood bank or guiding bank

    Preventing of rock breaking

    Water and soil protection

    Bridge protection

    Strengthening structure of soil

    Protection engineering of seaside area


    Gabion box Features


    (1) It is convenient to use, and can be used only by tiling the net surface into wall surfaces and building cement;

    (2) The construction is simple and does not need special technology;

    (3) Strong ability to resist natural damage, corrosion and adverse weather effects;

    (4) Can withstand large-scale deformation without collapsing. It plays a role in fixing heat preservation and heat insulation.

    (5) The excellent technological foundation ensures the uniformity of coating thickness and has stronger corrosion resistance;

    (6) Save transportation costs. It can be shrunk into small rolls and wrapped in moisture-proof paper, occupying little space.

    Construction steps


    The construction combination and stone filling steps can be summarized as follows: Each unit structure is combined before placement The structure of the pad combination is placed at the construction site, and the cell structures are connected by tie wire. Rock fill in structure Cover the structure and fasten it with tie wire.
