cross razor wire bto-22

    Buy cheap cross razor wire bto-22 from wholesalers

    Buy cheap cross razor wire bto-22 from wholesalers
    • Buy cheap cross razor wire bto-22 from wholesalers

    cross razor wire bto-22

    Ask Lasest Price
    Brand Name : SHUXIN
    Model Number : SX-003
    Certification : PVOC, COC, SASO C/O
    Price : negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100 sets per week
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    cross razor wire bto-22

    All the specification and packing can be designed according to the customers need.

    ModelThicknessWire diaBarb LengthBarbed Width
    Barb Spacing
    BTO-100.5+/-0.05 mm2.5+/-0.1mm10+/-1mm13+/-1mm26+/-1mm
    BTO-120.5+/-0.05 mm2.5+/-0.1mm12+/-1mm15+/-1mm26+/-1mm
    BTO-180.5+/-0.05 mm2.5+/-0.1mm18+/-1mm15+/-1mm38+/-1mm
    BTO-220.5+/-0.05 mm2.5+/-0.1mm22+/-1mm15+/-1mm38+/-1mm
    BTO-280.5+/-0.05 mm2.5+/-0.1mm28+/-1mm15+/-1mm53+/-1mm
    BTO-300.5+/-0.05 mm2.5+/-0.1mm30+/-1mm21+/-1mm54+/-1mm
    CBT-600.6+/-0.05 mm2.5+/-0.1mm60+/-2mm32+/-1mm102+/-1mm
    CBT-650.3+/-0.05 mm2.5+/-0.1mm65+/-2mm21+/-1mm102+/-1mm
    Outside diameterNo. of loopsThe utmost effective lengthTypeNotes
    450 mm337 - 8 MCBT 60.65Single coil
    500 mm5612 - 13 MCBT 60.65Single coil
    700 mm5613 - 14 MCBT 60.65Single coil
    960 mm5614 - 15 MCBT 60.65Single coil
    450 mm568 - 9 M (3 CLIPS)BTO - 10.12.18.22.28.30Cross type
    500 mm569 - 10 M (3 CLIPS)BTO - 10.12.18.22.28.30Cross type
    600 mm5610 - 11 M (3 CLIPS)BTO - 10.12.18.22.28.30Cross type
    600 mm568 - 10 M (5 CLIPS)BTO - 10.12.18.22.28.30Cross type
    700 mm5610 - 12 M (5 CLIPS)BTO - 10.12.18.22.28.30Cross type
    800 mm5611 - 13 M (5 CLIPS)BTO - 10.12.18.22.28.30Cross type
    900 mm5612 - 14 M (5 CLIPS)BTO - 10.12.18.22.28.30Cross type
    960 mm5613 - 15 M (5 CLIPS)BTO - 10.12.18.22.28.30Cross type
    980 mm5614 - 16 M (5 CLIPS)BTO - 10.12.18.22.28.30Cross type


    cross razor wire bto-22

    Customization: Available
    Material: Galvanized Steel Wire
    Twist Method: Corros Type
