    Heigh 2' Sand Filled Hesco 2x1x1 Height Defensive Barrier With Geotextile Filter Fabric

    Ask Lasest Price
    Brand Name : SHUXIN
    Model Number : Military Gabion Box
    Certification : ISO CE SGS COC
    Price : Negotiated
    Payment Terms : Western Union, MoneyGram, T/T, L/C
    Supply Ability : 100 units per week
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Heigh 2' Sand Filled Hesco 2x1x1 Height Defensive Barrier With Geotextile Filter Fabric

    Heigh 2' Sand Filled Hesco 2x1x1 Defensive Barrier With Geotextile Filter Fabric


    What is the Defensive Barrier ?


    Wire Mesh Box Retaining Walls Military Gabion Box For Army defensive barriers unit is made of welded mesh panels which are connected with spring wire.


    The unit is a multi-cellular wall system manufactured from welded Zinc-Aluminum coated /hot dipped galvanized steel wire mesh and joined with vertical,helical coil joints.
    The units are lined with either beige or green colored heavy-duty non-woven polypropylene geotextile.Hesco barrier /hesco bastion can be filled with sand, earth, cement,stone, then as a defence wall or bunker and widely used in the military to protect safety.


    Specification of Defensive Barrier :


    1) wire diameter: 4mm - 5mm
    2) hole: 2''x2'',3''x3'',4''x4''
    3) hesco size: 0.61x0.61m,1x1m,2.13x2.21m,other size can be produced as requested.
    4) geotextile: in non-woven geotextile,color can be green,beige-sand color.


    Defensive Barrier Specification


    ModelHeightWidthLengthInternal Cells
    SX-154”(1.37m)42”(1.06m)32’9”(10m)5+4=9 cells
    SX-224”(0.61m)24”(0.61m)4’(1.22m)2 cells
    SX-339”(1.0m)39”(1.0m)32’9”(10m)5+5=10 cells
    SX-439”(1.0m)60”(1.52m)32’9”(10m)5+5=10 cells
    SX-524”(0.61m)24”(0.61m)10’(3.05m)5 cells
    SX-666”(1.68m)24”(0.61m)10’(3.05m)5 cells
    SX-787”(2.21m)84”(2.13m)91’(27.74m)5+4+4=13 cells
    SX-854”(1.37m)48”(1.22m)32’9”(10m)5+4=9 cells
    SX-939”(1.0m)30”(0.76m)30’(9.14m)6+6=12 cells
    SX-1087”(2.21m)60”(1.52m)100’(30.5m)5+5+5+5=20 cells
    SX-1148”(1.22m)12”(0.30m)4’(1.22m)2 cells
    SX-1284”(2.13m)42”(1.06m)108’(33m)5+5+5+5+5+5=30 cells
    SX-19108”(2.74m)42”(1.06m)10’5”(3.18m)6 cells

    Defensive Barrier Use Deatils:


    Unpack---Pull out and set up-----Connect together---- Fill and compact----Finished
