Height 3'3" Galvanized Hesco Barrier Welded Mesh Galvanized Iron
Wire Square For Protection
Defensive Hesco Barrier Introduction :
Military wall defensive barrier is gabion-like. It is a combination
of welded wire mesh frame outside and non-woven geotextile liner
inside. Sand, soil, gravel and blinding are frequently used as
filling because of geotextile liner.
Military wall defensive barrier are mainly used in military and
flood control for its modular structure and quick setup. For
military, a gabion Hesco with 24 inches thickness can stop rifle
bullets, shell fragments and other shrapnel. While for flood
protection, gabion Kesco can be assembled soonest and come into use
.
In addition to the standard Container unit, is constantly
developing its portfolio of products in response to its customers’
requirements. Multi-cellular wall system force protection product .
Military wall Defensive Hesco Barrier Installation:
1. Unpack the collapsible wire mesh container from package.
2. Unfold the barrier and connect barriers to reach the designed
length
3. Fill soil, sand or gravel into the container. The common machine
is front end loader.
4. Compact the content
5. Add layers if required
Defensive Hesco Barrier Specification
| Model | Height | Width | Length | Internal Cells |
| SX-1(Mil 1) | 54”(1.37m) | 42”(1.06m) | 32’9”(10m) | 5+4=9 cells |
| SX-2(Mil 2) | 24”(0.61m) | 24”(0.61m) | 4’(1.22m) | 2 cells |
| SX-3(Mil 3) | 39”(1.0m) | 39”(1.0m) | 32’9”(10m) | 5+5=10 cells |
| SX-4(Mil 4) | 39”(1.0m) | 60”(1.52m) | 32’9”(10m) | 5+5=10 cells |
| SX-5(Mil 5) | 24”(0.61m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-6(Mil 6) | 66”(1.68m) | 24”(0.61m) | 10’(3.05m) | 5 cells |
| SX-7(Mil 7) | 87”(2.21m) | 84”(2.13m) | 91’(27.74m) | 5+4+4=13 cells |
| SX-8(Mil 8) | 54”(1.37m) | 48”(1.22m) | 32’9”(10m) | 5+4=9 cells |
| SX-9(Mil 9) | 39”(1.0m) | 30”(0.76m) | 30’(9.14m) | 6+6=12 cells |
| SX-10(Mil 10) | 87”(2.21m) | 60”(1.52m) | 100’(30.5m) | 5+5+5+5=20 cells |
| SX-11(Mil 11) | 48”(1.22m) | 12”(0.30m) | 4’(1.22m) | 2 cells |
| SX-12(Mil 12) | 84”(2.13m) | 42”(1.06m) | 108’(33m) | 5+5+5+5+5+5=30 cells |
| SX-19(Mil 19) | 108”(2.74m) | 42”(1.06m) | 10’5”(3.18m) | 6 cells |
Defensive Hesco Barrier Application :
1. Environmental Barriers,Flood Barriers, a reliable, easy-to-deploy
and robust solution for emergency flood protection or long-term
wetland restoration
2. Defensive Barriers: Protecting both military and civilian
personnel in dangerous environments demands defensive solutions
that are secure, reliable and readily available.
3. Protective Barriers: Protect your workforce,Create a secure refuge
for your employees by
providing protection for up to eight people with Accommodation
Bunker.
4. Rockface: transforms the highly effective wall into an
aesthetically pleasing structure ideal for customer-facing
perimeter security where a more benign appearance is required.
We have specialized equipments and professional inspectors. We can supply the quality assurance to the customer.
Due to our hard working technicians and the continuously pursue of
outstanding quality, we have exported our product to Northern
America, Europe, South Africa, Latin America, the Middle East, the
Oceania, and Asia, etc.
