Portable Weld Square 3x3" (7.62*7.62 cm) Military Defensive Stone
Box Barriers In Ghana
Material : All wires conform to BS EN10218-2012,Zinc-Alunminum
coating are to BS EN 10244-2:2009
Geotextile: heavy duty geotextile, non-woven,permeable,
polypropulene farbric
Geotextile color: beige or green color
Mesh Hole: 3” X 3”
Unit Size : 2.13m x 1.06m x 33m
Cells:1unit=5 cells+5cells+5cells+5cells+5cells+5cells=30cells
A geotextile lined unit for general use as an earth filled barrier
.
The units are suitable for filling with earth ,sand,gravel,crushed
rock and other granular materials.
The unit fulfills a wide range of users,including the construction
of protective walls and barriers.
The Dimension / Specification for Military Defensive Stone Box Barriers:
Product Name | Hesco Barrier |
Product Type | Welded Mesh |
Material | Galvanized Steel Wire or Galfan/zinc-5% Aluminum Wire |
Wire Diameter | 4.0, 5.0mm, Spring Wire Diameter: 4mm |
Geotextile | 250g-400g |
Geotextile colour | Sand clolor, Brown, Gray,and Military Green. |
Mesh hole | 76.2mm× 76.2mm, 50mm× 50mm, 75mm× 75mm, 100mm× 100mm |
Military Gabion Barrier Bastion Sand Wall is a multi-cellular
barrier system lined with heavy-duty, non-woven polypropylene
geotextile and manufactured from welded Zinc-Aluminium coated steel
mesh.
Known as a Military Gabion Barrier Bastion Sand Wall , it consists
of collapsible wire mesh frames, lined with heavy duty canvas or
other material. The boxes are then filled with dirt or sand ,
preferably with a front-end loader , to make a barrier resistant to
small arms fire and shrapnel.
Brief Introduction for Usage method:
1. Usually the HESCO Barriers packed in Pallet and 5 cells per
set,After getting it, make it stand.
2. To Pull them, make them opened and in a line to achieve the length
you want, If more cells use Joint Pin
3. Full Fill the sand and earth in it and compaction
4. If you want more High and Wide of it, You can stack the HESCO
Barrier on each other.
Defense barriers come in many sizes. Most fences can also be
stacked and packed into a compact set. Whether used as protective
barriers or to define borders, security barriers and T-walls are
used to protect equipment, facilities, vehicles and personnel in
military, peacekeeping, humanitarian and civil operations.
The Size Sheet for Military Defensive Stone Box Barriers:
| MODEL | Height | Width | Length | NO. of Cells |
| SX-1 | 4'6"(1.37M) | 3'6"(1.06M) | 32'(10M) | 9 cells(1*4, 1*5) |
| SX-2 | 7'(2.1M) | 3'6"(1.06M) | 108'(33M) | 30 cells(6*5) |
| SX-3 | 2'(0.61M) | 2'(0.61M) | 4'(1.21M) | 2 cells |
| SX-4 | 3'3"(1.0M) | 3'3"(1.0M) | 32'(10M) | 10 cells(2*5) |
| SX-5 | 2'(0.61M) | 2'(0.61M) | 10'(3.05M) | 5 cells |
| SX-6 | 5'6"(1.68M) | 2'(0.61M) | 10'(3.05M) | 5 cells |
| SX-7 | 7'3"(2.21M) | 7'(2.13M) | 90'(27.74M) | 13 cells(2*4,1*5) |
| SX-8 | 4'6"(1.37M) | 4'(1.22M) | 32'(10M) | 9 cells(1*4, 1*5) |
| SX-9 | 3'3"(1.0M) | 2'6"(0.76M) | 30'(9.14M) | 12 cells(2*6) |
| SX-10 | 7'(2.12M) | 5'(1.52M) | 95'(30.5M) | 20 cells(4*5) |
| SX-11 | 3'3"(1.0M | 3'3"(1.0M) | 3'3"(1.0M) | 1 Cell |
| SX-12 | 7'3"(2.21M) | 7'3"(2.21M) | 7'3"(2.21M) | 1 Cell |
The Detailed Explanation of Application for Military Defensive Stone Box Barriers:
1. Military Fortifications
Most Army Used HESCO Barrier build up a Military Fortifications,
Because it can stack on each other, You can change the width and
height by your demands. More easy and flexible.
2. Shooting Range
Nowadays, A lot of people use HESCO Barrier to build a shooting
range, because its High Strength Defense, more safety.
3. Flood Control
We Mentioned above, The HESCO Barrier is more and more popular and
Homemade. Most Countries Near the coastline choose the HESCO
Barrier as Flood Protection Wall.Even around the hotel they stand
up the HESCO Barrier for Protection Wall.
The Advantages for Military Defensive Stone Box Barriers:
1. Collapsible
It is assembled by Panel and Spring Wire, When Loading and
transportation, It is Foldable into one piece.
2. Anti-Corrosion
The Raw material is Hot Dipped Galvanized Wire, it can use 10 years
even more longer, fit for outside protection.
3. Easy Installation
After getting it, Just put it in the right place and open it, Full
filled the sand and earth is okay. Even 2-3 persons can finish it.
4. Quick Displacements
When you want to use it in another place,Just to move it, It can
use many times
5. Easy to repair
If some part is destroyed, Just left it and connect the new one is
okay.
SHUXIN company had been produce welded wire mesh products hesco
barriers more than 15 years.
our products been supplied many countries's department of defense.
and army force.
such as UAE Jordan, USA,Greece,Saudi Aria, Dubai,Kenya ....
and our factory had been verified onsite by world-leading
inspection company SGS Group.
we have CE ISO certification. and we have confidence to become your
stable and believable supplier in China.
Welcome inquiry for us about hesco barriers.
