Anti-Ram Defensive Bastion Barrier Crash Tested for Perimeter
Security Wall
Defensive Bastion Wall is is a combination of welded wire mesh frame outside and
non-woven geotextile liner inside. Sand, soil, earth, gravel and
blinding are frequently used as filling inside which can prevent by
Heavy non-woven geotextile cloth.Its life can last 15- 20 years in
the normal condition. Most Gabion Bastion Wall are widely used in
Military or Shooting Range.
The Defensive Barrier Bastion is a cutting-edge security solution engineered to withstand
extreme threats, from explosive blasts and ballistic impacts to
natural disasters. Combining military-grade durability with modular
design, this barrier system redefines perimeter defense for
high-risk environments.
Brief Introduction for Flood Control Bastion Wall:
Material: Galvanized steel wire or Galfan / zinc-5%aluminum wire
Service Life: 15-20 years
Wire diameter: 3.0mm- 6.0mm
Aperture: 3" (76.2mm × 76.2mm ) Standard
Color of geotextile: Grey and Military, Beige, Sand Color and so
on.
Weight of Geotextile: 250 g/m2 or 300 g/m2
Finish:hot dipped galvanized,Galfan wire.
Welded method:welded after galvanized or galvanized after welded
The Standard Technical Specifications
| Welded Mesh Military Base Wall |
| Model | Height | Width | Length |
| MIL-1 | 54"(1.37M) | 42"(1.06M) | 32'9"(10M) |
| MIL-2 | 24"(0.61M) | 24"(0.61M) | 4'(1.22M) |
| MIL-3 | 39"(1.00M) | 39"(1.00M) | 32'9"(10M) |
| MIL-4 | 39"(1.00M) | 60"(1.52M) | 32'9"(10M) |
| MIL-5 | 24"(0.61M) | 24"(0.61M) | 10'(3.05M) |
| MIL-6 | 66"(1.68M_ | 24"(0.61M) | 10'(3.05M) |
| MIL-7 | 87"(2.21M) | 84"(2.13M) | 91'(27.74M) |
| MIL-8 | 54"(1.37M) | 48"(1.22M) | 32'9"(10M) |
| MIL-9 | 39"(1.00M) | 30"(0.76M) | 30'(9.14M) |
| MIL-10 | 87"(2.21M) | 60"(1.52M) | 100'(32.50M) |
| MIL-11 | 48"(1.22M) | 12"(0.30M) | 4'(1.22M) |
| MIL-12 | 84"(2.13M) | 42"(1.06M) | 108'(33M) |
| MIL-19 | 108"(2.74M) | 42"(1.06M) | 10'5"(3.18M) |
The Application for Defensive Bastion Wall
Flood Control
1. Flood Prevention Barrier
From a simple perimeter wall to a complex base infrastructure,
SHUXIN products provide rapid expeditionary protection
2. Permanent or Semi-permanent Dike
gabion Barriers can as the Dike against the Flood permanently or
Semi-Permanently.
3. Flood Control Retaining Wall
Wiht sand and earth in it, Military Gabion Box can as a retaining
Wall to against the flood.
4. Protection Engineering of Seaside Area
Military Defensive Bastion is more and more homemade at the seaside
area as Protection Fence
5. Protecting Existing Structures
6. Coastal Erosion Control
The Advantages of Defensive Bastion Wall:
1. Lifetime
The unit must be made of a Wire Mesh basket which is manufactured
from Galvanised coated, welded mesh. The mesh must be made of rust
protected alloy materials.The Wire Mesh must have a guaranteed life
of not less than 5 years while exposed to environment and 10 years
when in store.
2. Collapsible
Mesh Panel is joint by spring which is a circle, Mesh Panle can
turn 360° unobstructed, so, when shiping the goods, it is
collapsible to save space.
3. Strong Protection
Thickner Mesh Panle together with thickner geotextile combined a
strong Protection wall.
4. Fast and Simple Operation
A security wall using Welded earth-filled barrier can be filled by
two persons and a standard front-end loader in just 20 minutes, the
equivalent sized wall of 1,500 sandbags will take 10 persons up to
7 hours to fill and build.
