    Double Twist Weave Hexagon 2.7MM Gabion Wall Cages Rockfall Protection Netting

    Ask Lasest Price
    Brand Name : SHUXIN
    Certification : ce
    Price : Negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Delivery Time : 5-15 DAYS
    • Product Details
    • Company Profile

    Double Twist Weave Hexagon 2.7MM Gabion Wall Cages Rockfall Protection Netting

    Double Twist Weave Hexagon Gabion Box Mesh Price Rockfall Protection Netting Gabion Walls


    Gabion refers to PVC coating on zinc coating wire fabric containers that comes in variable sizes with rocks filling to form a permanent structure. And the Green Gabion Mattress, also known as Gabion Mattress System by Fibromat makes a great Earth Retention System caters for slopes erosion control, toe and river bank protection, maximizing permeability on the structure while providing reinforcement and grass establishment.


    Gabion Mattresses serves as a retaining wall, providing various prevention and protection works such as landslide prevention, erosion and scour protection as well as various type of hydraulic and coastal protection for river, sea and channel protection. This Gabion Mattress System is made up of a specially designed composite in order to maximize its performance through three phases of vegetative process from vegetated to vegetation establishment up to vegetation maturation.


    Gabion mesh/ gabion box material:

    (1) Galvanized steel wire: diameter 2.0MM-4.0MM, tensile strength >380Mpa, zinc :240g / m2.

    (2) Zinc 5% Aluminum - wire diameter 1.0MM-3.0MM, tensile strength >380Mpa.

    (3) coated galvanized steel wire: low carbon steel wire PVC coated.

    (4) Woven Mesh Opening: Hexagonal Wire Pattern 60*80mm, 80*100mm,100*120mm,

    (5) Size: 1*1*1m,2*1*1m, 4*1*1x2m, other size can be produced as requested

    Gabion box

    (mesh size):

    80*100mm

    100*120mm

    Mesh Wire diameter2.7mmzinc coating:60g,245g, ≥270g/m2
    Edge wire diameter3.4mmzinc coating:60g,245g, ≥270g/m2
    Tie wire diameter.2.2mmzinc coating:60g,≥220g/m2

    Gabion mattress

    (mesh size):

    60*80mm

    Mesh wire diameter.2.2mmzinc coating:60g, ≥220g/m2
    Edge wire diameter.2.7mmzinc coating:60g,245g, ≥270g/m2
    Tie wire diameter.2.2mmzinc coating:60g, ≥220g/m2

    special sizes Gabion

    are available


    Mesh wire diameter2.0~4.0mm

    superior quality,competitive price and

    considerate service

    Edge wire diameter2.7~4.0mm
    Tie wire diameter2.0~2.2mm

    Why choose our gabion box?

    Economic. Just fill the stone into the gabion and seal it.

    Easy to install.

    High zinc coating thus anti-rust and anti-corrosive.

    Low cost and High security.

    Good permeation can prevent the damage by hydrostatic pressure
    Less transport freight. It can be folded together for transport and further installation.


    Gabion Cage Advantage:


    Flexibility: Flexibility is an important benefit of any gabion structure. The double-twist hexagonal mesh construction permits it to tolerate differential settlement without fracture. This property is especially important when a structure is on unstable soil conditions or in areas where scour from wave action or currents can undermine the toe of the structure and cause structural settlement.
    Durability: Gabions support plant growth which provides a live coating for the wire mesh and stones, adding to their durability. Generally, the wire mesh is needed for the first few years of the structure’s life; later the void between the stones is filled with soil, silt, and plant roots which act as a bonding agent for the stones.
    Strength: Steel wire hexagonal mesh has strength and flexibility to withstand forces generated by water and earth masses, and the pervious nature of the gabion allows it to absorb and dissipate much of that energy. This is evident on coast protection installations where gabion structures remain effective long after a massive rigid structure fails. Additionally, the double twisted hexagonal mesh won’t unravel if cut.
    Permeability: Gabion walls are previous to water and stabilize slopes by the combined action of draining and retaining, precluding the development of hydrostatic pressure behind the gabion wall. Drainage is accomplished by gravity, as well as evaporation as the porous structure permits air circulation through it. As plant growth develops within the structure, the process of transpiration assists in removing moisture from the backfill – a much more efficient system than weep holes in standard masonry walls.
    Low cost: Gabion systems are more economical than rigid or semi-rigid structures for the following reasons:
    • It requires little maintenance
    • Its installations does not require skilled labor and stone fill is available on site or from nearby quarries,
    • It requires little or no foundation preparation, as the surface needs to be only reasonably level and smooth.


    Gabion basket application:

    Control and guide of water or flood

    Flood bank or guiding bank

    Preventing of rock breaking

    Water and soil protection

    Bridge protection

    Strengthening structure of soil

    Protection engineering of seaside area


    Construction steps

    The construction combination and stone filling steps can be summarized as follows: Each unit structure is combined before placement The structure of the pad combination is placed at the construction site, and the cell structures are connected by tie wire. Rock fill in structure Cover the structure and fasten it with tie wire.
